Summit CR2B122 21″ Wide 2-Burner Electric Coil Cooktop – Stainless Steel Surface, 115 V, Compact Drop-In Fit

SKU: SA-CR2B122
(0)
$415.30
Standard 115 V / 20 Amp Operation with Cord Included – Simple Install – Operates on typical household circuits and ships with a plug-in cord for plug-and-play setup without complex wiring.
Durable Stainless Steel Surface – Easy to Clean & Resists Wear – Stainless finish gives a clean, professional look and simplifies cleanup after cooking.
Two Coil Burners (7″ / 900 W & 5.5″ / 500 W) for Flexible Cooking – Large burner handles bigger pots and faster heating while the smaller burner is ideal for simmering or small cookware.
3.38" H x 21.25" W x 18.0" D
(9cm H x 54cm W x 46cm D)
5 years - Compressor Warranty
1 year - Parts & Labor Warranty
Free Freight Shipping - Includes lift-gate service (curbside delivery). White Glove service available by quote: 800-626-0854 or sales@hegemonsupply.com

Customer service

Video chat Chat Email 800-626-0854

Features

  • SKU SA-CR2B122

2-Burner Radiant Cooktop:
115V coil cooktop designed to fit popular 20" x 16" cutouts in hotels and other smaller kitchen spaces

Versatile placement:
Specially designed to be mounted portrait or landscape style with controls being easy to read and manage in either direction

Stainless steel finish:
Surface is made from stainless steel for an attractive and easy to clean look

Fits popular cutout size:
Designed for built-in installation in 20" x 16" cutouts

Two heating elements:
One 900W 7" coil element and one 500W 5 1/2" coil element

115V operation:
Designed to work with standard 115V/60Hz electrical supplies with proper grounding

Push-to-turn knobs:
Prevents accidents by requiring a small amount of force to turn on cooktop heat

Indicator lights:
Operating indicators light up to show which burner is in use

Cord included:
Pre-installed cord with a 115V NEMA 5-15P 3-pronged plug for easier setup

ADA compliant design:
Upfront controls and easy-to-operate knobs offer easier accessibility

Summit offers a quality lineup of electric cooktops designed to suit any residential or hotel kitchen setup.

The CR2B122 is a 120V cooktop made from attractive stainless steel. This unit is designed to fit many common counter cutouts sized 20" x 16". The burners and knobs are specially laid out so that they are easy and intuitive to use when the unit is installed in a landscape or portrait configuration.

This unit features a large 7" 900W coil element and a 5 1/2" 500W coil element, letting you accommodate a variety of sizes. Additional safety features include indicator lights and push-to-turn knobs.

With its innovative design and quality construction, the CR2B122 brings modern convenience to a classic cooktop size.

 Overview

Refrigerator-Freezer
Nominal Height 3.38" (9 cm) Heating Type Radiant
Height of Cabinet 3.38" (9 cm) Surface Stainless Steel
Nominal Width 22.0" (56 cm) Element Type Coils
Width 21.25" (54 cm) Number of Elements 2
Nominal Depth 18.0" (46 cm) Controls Dial
Depth 18.0" (46 cm) Countertop Cutout Height 3.0" (8 cm)
Cabinet Stainless Steel Countertop Cutout Width 20.0" (51 cm)
US Electrical Safety ETL Countertop Cutout Depth 16.0" (41 cm)
Canadian Electrical Safety ETL-C Element #1 Size 5.5" (14 cm)
Amps 20.0 Element #1 Wattage 500.0
Voltage/Frequency 115 V AC/60 Hz Element #2 Size 7.0" (18 cm)
Weight 5.0 lbs. (2 kg) Element #2 Wattage 900.0
Parts & Labor Warranty 1 Year Power Cord Included Yes
UPC 761101050478

BROCHURE

ASSEMBLY DRAWING

SUPPORT

WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov. Note: Nickel is a component of stainless steel.
