Summit CK55ADASINKR 54.13" Wide 3.2 Cu.Ft. All-In-One ADA Kitchenette – Smooth-Top Cooktop, Black/Stainless Steel
🔒 Secure Checkout
Need Help Choosing the Right Equipment?
Our specialists can help with product selection, freight coordination, installation questions, and bulk quotes.
Summit Appliance Product Template
Description & Features
The Summit CK55ADASINKR is a 54-inch ADA-compliant all-in-one kitchenette designed for apartments, studios, assisted living facilities, dormitories, hotels, and other compact spaces. This freestanding unit combines a 3.2 cu.ft. refrigerator-freezer, two-burner smooth-top cooktop, stainless steel sink with faucet, and multiple storage cabinets in a space-saving design. The included ENERGY STAR certified refrigerator features a dual evaporator system, adjustable glass shelving, and a reversible door for flexible food storage and improved cooling performance.
Features
- ADA-compliant 34" counter height for improved accessibility.
- Complete kitchenette with refrigerator, sink, cooktop, and storage cabinets.
- 3.2 cu.ft. refrigerator-freezer with dual evaporator cooling.
- Two-burner smooth-top electric cooktop with push-to-turn controls.
- Stainless steel sink with pre-installed gooseneck faucet.
- Reversible refrigerator door with adjustable glass shelf and crisper drawer.
Specifications
Overview
| Nominal Height | 34.0" (86 cm) |
| Height of Cabinet | 34.0" (86 cm) |
| Nominal Width | 55.0" (140 cm) |
| Width | 54.13" (137 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 23.75" (60 cm) |
| Depth with door at 90° | 39.13" (99 cm) |
| Capacity | 3.2 cu.ft. (91 L) |
| Defrost Type | Cycle |
| Door | Black/SS |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Energy Usage/Year | 322.0kWh/year |
| Other Energy Info | Cooktop is 20 Amps; Refrigerator-Freezer is 1.1 Amps |
| Amps | 21.1 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 145.0 lbs. (66 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101089102 |
Refrigerator-Freezer
| Refrigerator Included | CP34BSS |
| Refrigerator Door Swing | RHD |
| Reversible | Yes |
| Adjustable Shelves | Yes |
| Shelf Type | Glass |
| Shelf Qty | 1 |
| Crisper Qty | 1 |
| Crisper Finish | Transparent |
| Crisper Cover | Glass |
| Full Door Shelves | 2 |
| Can Storage | Yes |
| Thermostat Type | Dial |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.16 oz. |
| High Side PSI | 250.0 |
| Low Side PSI | 88.0 |
| Cooking Type | Smooth-Top Cooktop |
| Number of Burners | 2 |
| Cooktop Controls | Dial |
| Interior Height 1 | 18.5" (47 cm) |
| Interior Width 1 | 15.75" (40 cm) |
| Interior Depth 1 | 15.0" (38 cm) |
| Interior Height 2 | 7.5" (19 cm) |
| Interior Width 2 | 14.0" (36 cm) |
| Interior Depth 2 | 14.0" (36 cm) |
| Sink Height | 4.0" (10 cm) |
| Sink Width | 11.0" (28 cm) |
| Sink Depth | 13.0" (33 cm) |
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov. Note: Nickel is a component of stainless steel.
