Summit BRF631BKY 24" Wide 5.1 cu.ft. Refrigerator-Freezer – Panel-Ready Black
🔒 Secure Checkout
Need Help Choosing the Right Equipment?
Our specialists can help with product selection, freight coordination, installation questions, and bulk quotes.
Summit Appliance Product Template
Description & Features
The Summit BRF631BKY is a 24" wide refrigerator-freezer designed for residential kitchens, hospitality suites, wet bars, and undercounter applications. Featuring a 5.1 cu.ft. capacity, cycle defrost operation, dual evaporator cooling, adjustable glass shelves, and a panel-ready door front, this compact refrigerator-freezer provides flexible food and beverage storage with customizable installation capability and a seamless built-in appearance.
Features
- Dual evaporator cooling system separates refrigerator and freezer temperatures
- Cycle defrost operation with separate freezer compartment
- Panel-ready door accepts custom overlay panels
- Adjustable glass shelves for flexible storage organization
- Built-in capable front-breathing design for undercounter installation
- Reversible door swing for installation flexibility
Specifications
Overview
| Nominal Height | 33.0" (84 cm) |
| Height of Cabinet | 32.63" (83 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.63" (60 cm) |
| Nominal Depth | 23.0" (58 cm) |
| Depth | 23.0" (58 cm) |
| Depth with Handle | 24.5" (62 cm) |
| Depth with door at 90° | 45.25" (115 cm) |
| Capacity | 5.04 cu.ft. (143 L) |
| Defrost Type | Cycle |
| Door | Yellow |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Energy Usage/Year | 330.0kWh/year |
| Amps | 1.2 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 110.0 lbs. (50 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101087764 |
Refrigerator-Freezer
| Door Swing | RHD |
| Reversible | Yes |
| Adjustable Shelves | Yes |
| Crisper Qty | 1 |
| Crisper Finish | Transparent |
| Crisper Cover | Glass |
| Wine Bottle Shelving | Yes |
| Interior Light | Yes |
| Refrigerator - Interior Height | 18.0" (46 cm) |
| Refrigerator - Interior Width | 21.0" (53 cm) |
| Refrigerator - Interior Depth | 18.0" (46 cm) |
| Refrigerator - Capacity | 4.5 cu.ft |
| Refrigerator - Shelf Type | Glass |
| Refrigerator - Shelf Qty | 2 |
| Refrigerator - Full Door Shelves | 3 |
| Freezer - Interior Height | 5.25" (13 cm) |
| Freezer - Interior Width | 19.0" (48 cm) |
| Freezer - Interior Depth | 11.5" (29 cm) |
| Freezer - Capacity | 0.6 cu.ft |
| Thermostat Type | Dial |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.92 oz. |
| High Side PSI | 180.0 |
| Low Side PSI | 80.0 |
| Compressor Step Height | 5.5" (14 cm) |
| Compressor Step Width | 21.0" (53 cm) |
| Compressor Step Depth | 6.0" (15 cm) |
