Summit CT66LWBISSHH 23.63" Wide 5.1 Cu.Ft. Built-In Refrigerator-Freezer – Stainless Steel, Dual Evaporator Cooling
🔒 Secure Checkout
Need Help Choosing the Right Equipment?
Our specialists can help with product selection, freight coordination, installation questions, and bulk quotes.
Summit Appliance Product Template
Description & Features
The Summit CT66LWBISSHH is a 5.1 cu.ft. refrigerator-freezer designed for built-in or freestanding installation in commercial, healthcare, laboratory, and institutional settings. This compact 24" wide unit features a front-breathing system for built-in installation, Summit's dual evaporator cooling technology for improved refrigerator and freezer performance, cycle defrost operation, and a factory-installed lock for secure storage. A stainless steel wrapped door with a horizontal towel bar handle provides a professional appearance, while adjustable wire shelves, a crisper drawer, interior lighting, and a reversible door offer convenient storage flexibility.
Features
- Built-in capable front-breathing design for undercounter installation
- Stainless steel wrapped door with horizontal towel bar handle
- Dual evaporator cooling system for improved temperature performance
- Factory-installed keyed lock for secure storage
- Cycle defrost operation with automatic refrigerator defrost
- Reversible door swing with adjustable wire shelves and crisper drawer
Specifications
Overview
| Nominal Height | 34.0" (86 cm) |
| Height of Cabinet | 33.5" (85 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.63" (60 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 25.63" (65 cm) |
| Depth with door at 90° | 45.63" (116 cm) |
| Capacity | 5.1 cu.ft. (144 L) |
| Defrost Type | Cycle |
| Door | Stainless Steel |
| Cabinet | White |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.4 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 100.0 lbs. (45 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101068862 |
Refrigerator-Freezer
| Door Swing | RHD |
| Reversible | Yes |
| Adjustable Shelves | Yes |
| Crisper Qty | 1 |
| Crisper Finish | Transparent |
| Crisper Cover | Wire |
| Interior Light | Yes |
| Refrigerator - Interior Height | 19.5" (50 cm) |
| Refrigerator - Interior Width | 20.5" (52 cm) |
| Refrigerator - Interior Depth | 17.0" (43 cm) |
| Refrigerator - Shelf Type | Wire |
| Refrigerator - Shelf Qty | 2 |
| Refrigerator - Full Door Shelves | 3 |
| Freezer - Interior Height | 5.0" (13 cm) |
| Freezer - Interior Width | 19.0" (48 cm) |
| Freezer - Interior Depth | 11.5" (29 cm) |
| Thermostat Type | Dial |
| Fan Type | Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.92 oz. |
| High Side PSI | 180.0 |
| Low Side PSI | 80.0 |
| Level Legs | 4 |
| Compressor Step Height | 7.0" (18 cm) |
| Compressor Step Width | 20.5" (52 cm) |
| Compressor Step Depth | 5.0" (13 cm) |
