Summit FF6LWBIPLUS2ADA 24" Wide 5.5 Cu.Ft. ADA Compliant Medical Refrigerator – NIST Calibrated, Built-In, White
🔒 Secure Checkout
Need Help Choosing the Right Equipment?
Our specialists can help with product selection, freight coordination, installation questions, and bulk quotes.
Summit Appliance Product Template
Description & Features
The Summit FF6LWBIPLUS2ADA is a 5.5 cu.ft. ADA-compliant medical refrigerator designed for healthcare facilities, clinics, physician offices, pharmacies, and laboratory environments requiring reliable refrigerated storage between 2°C and 8°C. This built-in capable all-refrigerator features a NIST-calibrated temperature display with buffered glycol probe, digital thermostat, automatic defrost operation, fan-forced cooling, factory-installed lock, adjustable wire shelves, and a front-breathing system for undercounter installation in ADA-compliant spaces.
Features
- NIST-calibrated temperature display with min/max readout
- Buffered glycol temperature probe for simulated product temperatures
- ADA-compliant 32" installation height
- Built-in capable front-breathing design
- Automatic defrost operation
- Digital thermostat controls
- Internal fan for temperature uniformity
- Factory-installed keyed lock
- Adjustable wire shelves
- Temperature range of 2°C to 8°C (36°F to 46°F)
Specifications
Overview
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 32.0" (81 cm) |
| Height to Hinge Cap | 32.25" (82 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.63" (60 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 25.13" (64 cm) |
| Depth with door at 90° | 46.13" (117 cm) |
| Capacity | 5.5 cu.ft. (156 L) |
| Defrost Type | Automatic |
| Door | White |
| Cabinet | White |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.4 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 100.0 lbs. (45 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101070773 |
Refrigerator-Freezer
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Shelf Type | Wire |
| Shelf Qty | 3 |
| Full Door Shelf Qty | 3 |
| Adjustable Shelves | Yes |
| Thermostat Type | Digital |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.64oz. |
| High Side PSI | 180.0 |
| Low Side PSI | 80.0 |
| Level Legs Qty | 4 |
| Interior Light | Yes |
| Temperature Range | 2 to 8ºC / 36 to 46ºF |
| Interior Height | 27.75" (70 cm) |
| Interior Width | 20.0" (51 cm) |
| Interior Depth | 17.5" (44 cm) |
| Compressor Step Height | 7.0" (18 cm) |
| Compressor Step Width | 20.0" (51 cm) |
| Compressor Step Depth | 6.0" (15 cm) |
