Summit FF7LWBIADAGP 24" Wide 5.5 Cu.Ft. ADA Compliant All-Refrigerator – Built-In, Automatic Defrost, White
🔒 Secure Checkout
Need Help Choosing the Right Equipment?
Our specialists can help with product selection, freight coordination, installation questions, and bulk quotes.
Summit Appliance Product Template
Description & Features
The Summit FF7LWBIADAGP is a 5.5 cu.ft. ADA-compliant all-refrigerator designed for general-purpose cold storage in healthcare facilities, laboratories, offices, and institutional settings. Sized for installation under ADA-compliant counters, this built-in capable refrigerator features automatic defrost operation, an interior circulation fan for improved temperature uniformity, digital thermostat controls, adjustable wire shelving, a factory-installed lock, and a fully finished white cabinet that also allows freestanding use.
Features
- ADA-compliant 32" height for accessible installation
- Built-in capable front-breathing design
- Automatic defrost operation
- Interior fan for even cooling
- Factory-installed keyed lock
- Digital thermostat controls
- Adjustable wire shelves
- ETL-S listed to NSF-7 commercial standards
- Reversible door swing
- Fully finished cabinet for freestanding use
Specifications
Overview
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 32.0" (81 cm) |
| Height to Hinge Cap | 32.25" (82 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.63" (60 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 24.0" (61 cm) |
| Depth with door at 90° | 45.13" (115 cm) |
| Capacity | 5.5 cu.ft. (156 L) |
| Defrost Type | Automatic |
| Door | White |
| Cabinet | White |
| US Electrical Safety | UL |
| Canadian Electrical Safety | ULC |
| Sanitation | ETL-S |
| Amps | 1.4 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 100.0 lbs. (45 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101068121 |
Refrigerator-Freezer
| Door Swing | RHD |
| Reversible | Yes |
| Shelf Type | Wire |
| Shelf Qty | 3 |
| Adjustable Shelves | Yes |
| Thermostat Type | Digital |
| Fan Type | Interior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.64oz. |
| High Side PSI | 180.0 |
| Low Side PSI | 80.0 |
| Level Legs Qty | 4 |
| Interior Light | Yes |
| Temperature Range | 1 to 10°C |
| Interior Height | 26.25" (67 cm) |
| Interior Width | 21.0" (53 cm) |
| Interior Depth | 17.75" (45 cm) |
| Compressor Step Height | 5.5" (14 cm) |
| Compressor Step Width | 21.0" (53 cm) |
| Compressor Step Depth | 5.5" (14 cm) |
