Summit SWC008PNR 6" Wide 7-Bottle Built-In Wine Cellar – Panel-Ready Glass Door
🔒 Secure Checkout
Need Help Choosing the Right Equipment?
Our specialists can help with product selection, freight coordination, installation questions, and bulk quotes.
Summit Appliance Product Template
Description & Features
The Summit SWC008PNR is a slim 6-inch wide built-in wine cellar designed for undercounter installation in kitchens, bars, offices, and other space-conscious environments. This single-zone wine cooler accommodates up to 7 bottles and features a panel-ready glass door, digital temperature controls, fan-forced cooling, automatic defrost, and audible temperature and door alarms for reliable wine storage between 41°F and 72°F.
Features
- 7-bottle single-zone wine storage
- Panel-ready glass door with stainless steel trim
- Built-in undercounter installation design
- Digital thermostat with LED temperature display
- Fan-forced cooling for even temperature distribution
- Open door and high-temperature alarms
- Automatic defrost operation
- Reversible door swing with fully articulating hinge
Specifications
Overview
| Nominal Height | 34.0" (86 cm) |
| Height of Cabinet | 33.88" (86 cm) |
| Nominal Width | 6.0" (15 cm) |
| Width | 5.88" (15 cm) |
| Nominal Depth | 22.13" (56 cm) |
| Depth | 22.13" (56 cm) |
| Depth with Panel | 22.88" (58 cm) |
| Depth with door at 90° | 28.63" (73 cm) |
| Bottles | 7 bottles |
| Defrost Type | Automatic |
| Door | Glass/Panel-Ready Frame |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.0 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 44.0 lbs. (20 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101159812 |
Refrigerator-Freezer
| Number of Zones | 1 |
| Door Swing | RHD |
| Reversible | Yes |
| Thermostat Type | Digital |
| Interior Light | Yes |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.57 oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 105.0 |
| Interior Height 1 | 25.88" (66 cm) |
| Interior Width 1 | 3.5" (9 cm) |
| Interior Depth 1 | 14.25" (36 cm) |
| Compressor Step Height | 3.0" (8 cm) |
| Compressor Step Width | 3.5" (9 cm) |
| Compressor Step Depth | 6.0" (15 cm) |
| Temperature Range | 41 to 72ºF |
| Sabbath Mode | Yes |
| Sound Level | 33.8 dB |
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov. Note: Nickel is a component of stainless steel.
