Summit SWC530BLBISTCSSADA 23.63" Wide ADA Compliant 46-Bottle Dual Zone Built-In Wine Cellar – Stainless Steel
🔒 Secure Checkout
Need Help Choosing the Right Equipment?
Our specialists can help with product selection, freight coordination, installation questions, and bulk quotes.
Summit Appliance Product Template
Description & Features
The Summit SWC530BLBISTCSSADA is an ADA-compliant dual-zone wine cellar designed for built-in or freestanding installation under lower counters. This 24-inch unit stores up to 46 Bordeaux-style bottles and features independently controlled temperature zones for red and white wines, automatic defrost operation, digital thermostats, slide-out wooden shelves with stainless steel trim, LED lighting, and a factory-installed lock. Its 32-inch height makes it ideal for ADA-compliant residential installations.
Features
- ADA-compliant 32" high design
- Stores up to 46 Bordeaux-style wine bottles
- Dual temperature zones for red and white wines
- Automatic defrost system for reduced maintenance
- Digital thermostats with separate zone controls
- Slide-out wooden shelves with stainless steel trim
- Factory-installed keyed lock for added security
- Built-in capable with fully wrapped stainless steel cabinet
Specifications
Overview
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 32.0" (81 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.63" (60 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 23.38" (59 cm) |
| Depth with Handle | 25.0" (64 cm) |
| Depth with door at 90° | 45.5" (116 cm) |
| Bottles | 46 bottles |
| Defrost Type | Automatic |
| Door | Glass |
| Cabinet | Stainless Steel |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 2.0 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 112.0 lbs. (51 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101056425 |
Refrigerator-Freezer
| Number of Zones | 2 |
| Door Swing | RHD |
| Reversible | Yes |
| Shelf Type | Wood |
| Shelf Qty | 6 |
| Thermostat Type | Digital |
| Interior Light | Yes |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.23 oz. |
| High Side PSI | 150.0 |
| Low Side PSI | 50.0 |
| Level Legs | 2 |
| Sound Level | 34.3 dB |
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov. Note: Nickel is a component of stainless steel.
