Summit VC28S 24" Wide 28-Bottle Integrated Wine Cellar – Built-In, Stainless Steel Trim Glass Door
🔒 Secure Checkout
Need Help Choosing the Right Equipment?
Our specialists can help with product selection, freight coordination, installation questions, and bulk quotes.
Summit Appliance Product Template
Description & Features
The Summit VC28S is a 24-inch fully integrated wine cellar designed for premium residential and commercial wine storage. With capacity for up to 28 bottles, this single-zone unit features automatic defrost operation, digital temperature controls, slide-out wooden shelves, LED lighting, dynamic compressor cooling, and a reversible double-pane tempered glass door with seamless stainless steel trim. Its integrated design allows it to blend seamlessly into cabinetry while maintaining ideal wine storage conditions.
Features
- Stores up to 28 wine bottles
- Fully integrated built-in installation
- Automatic defrost operation
- Digital thermostat with Fahrenheit/Celsius display
- Dynamic compressor cooling system
- Slide-out wooden shelves
- Reversible UV-resistant double-pane glass door
- Open door alarm and temperature alarm
- LED interior lighting with showcase mode
- Humidity management system
- Sabbath Mode setting
- Meets UL-471 commercial standards
Specifications
Overview
| Nominal Height | 19.0" (48 cm) |
| Height of Cabinet | 18.13" (46 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.25" (59 cm) |
| Nominal Depth | 23.0" (58 cm) |
| Depth | 22.13" (56 cm) |
| Depth with Handle | 23.88" (61 cm) |
| Depth with door at 90° | 44.75" (114 cm) |
| Bottles | 28 bottles |
| Defrost Type | Automatic |
| Door | Glass |
| Cabinet | Unfinished |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.4 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 71.0 lbs. (32 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101031255 |
Refrigerator-Freezer
| Number of Zones | 1 |
| Door Swing | RHD |
| Reversible | Yes |
| Shelf Type | Wood |
| Shelf Qty | 3 |
| Thermostat Type | Digital |
| Interior Light | Yes |
| Fan Type | Interior |
| Refrigerant Type | R134a |
| Refrigerant Amount | 1.27 oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 105.0 |
| Interior Height 1 | 13.75" (35 cm) |
| Interior Width 1 | 18.88" (48 cm) |
| Interior Depth 1 | 14.88" (38 cm) |
| Temperature Range | 42º to 72ºF |
| Sabbath Mode | Yes |
