Summit VT65MLCSSADA 24″ ADA-Compliant Built-In Medical / All-Freezer – Stainless Steel Door, 3.5 cu. ft.
Customer service
Features
- SKU SA-VT65MLCSSADA
Accucold VT65MBIADA medical all-freezers offer low temperature storage in a perfectly sized footprint designed for built-in installation under lower ADA compliant counters.
The 32” high VT65MLCSSADA can be used built-in or freestanding in any 24” space, with low temperature manual defrost operation that can reach -25ºC. The interior includes three slide-out basket drawers for convenient storage that keep items cold when the door is opened. Additional features include an adjustable thermostat and one-piece interior liner for easier cleanup.
This medical unit has a stainless steel wrapped cabinet and door. A curved towel bar style handle in brushed stainless steel completes the look and a factory installed lock offers added security.
NOTE: ALL VT65M FREEZERS ARE DESIGNED FOR MEDICAL OR COMMERCIAL USE ONLY. THESE ARE NOT HOUSEHOLD FREEZERS.
|
Overview |
Refrigerator-Freezer |
|
|
| Nominal Height | 32.0" (81 cm) | Door Swing | RHD |
| Height of Cabinet | 32.0" (81 cm) | Reversible | Factory Reversible |
| Height to Hinge Cap | 32.25" (82 cm) | Height Adjustable | 1 |
| Nominal Width | 24.0" (61 cm) | Interior Height | 24.25" (62 cm) |
| Width | 23.63" (60 cm) | Interior Width | 17.75" (45 cm) |
| Nominal Depth | 24.0" (61 cm) | Interior Depth | 16.5" (42 cm) |
| Depth | 23.5" (60 cm) | Thermostat Type | Digital |
| Depth with Handle | 25.13" (64 cm) | Fan Type | Exterior |
| Depth with door at 90° | 46.0" (117 cm) | Refrigerant Type | R134a |
| Capacity | 3.5 cu.ft. (99 L) | Refrigerant Amount | 2.7 oz. |
| Defrost Type | Manual | High Side PSI | 235.0 |
| Door | Stainless Steel | Low Side PSI | 70.0 |
| Cabinet | Stainless Steel | Level Legs | 4 |
| US Electrical Safety | UL | Interior Drawers | Yes |
| Canadian Electrical Safety | ULC | Drawers Qty | 3 |
| Amps | 1.3 | Compressor Step Height | 6.5" (17 cm) |
| Voltage/Frequency | 115 V AC/60 Hz | Compressor Step Width | 17.5" (44 cm) |
| Weight | 105.0 lbs. (48 kg) | Compressor Step Depth | 5.5" (14 cm) |
| Parts & Labor Warranty | 1 Year | Temperature Range | -12ºC to -25ºC |
| Compressor Warranty | 5 Years | ||
| UPC | 761101043524 |
|
ASSEMBLY DRAWING |
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov. Note: Nickel is a component of stainless steel.
